MJ2-M32CKA-1U-***
MJ2-M32CKA-1.5U-***
MJ2-M32CKA-2U-***
Odering Information
Odering Information
Unloaded Video Jack Panels
Unloaded Panels for Canare Dual Video Jacks.
- Please refer to the image of ordering information.
- TECH DATA
[ Unloaded Video Jack Panels ]
| Type | Model | Panel Size | Jack Type | Description |
|---|---|---|---|---|
| NO IMAGE | VJ2-V20-1U-*** | 1 RU | DVJB | 20 ch (40 holes) |
| VJ2-V20-2U-*** | 2 RU | DVJB | 20 ch (40 holes) | |
| VJ2-V24-1U-*** | 1 RU | DVJB | 24 ch (48 holes) | |
| VJ2-V24-2U-*** | 2 RU | DVJB | 24 ch (48 holes) | |
| VJ2-V26-1U-*** | 1 RU | DVJB | 26 ch (52 holes) | |
| VJ2-V26-2U-*** | 2 RU | DVJB | 26 ch (52 holes) | |
| MJ2-M32-1U-*** | 1 RU | MDVJ and SVJK | 32 ch (64 holes) | |
| MJ2-M32-1.5U-*** | 1.5 RU | MDVJ and SVJK | 32 ch (64 holes) | |
| MJ2-M32-2U-*** | 2 RU | MDVJ and SVJK | 32 ch (64 holes) | |
| VJ2-M32-4U | 4 RU | MDVJ | 96 ch (3 x 32 ch, 192 holes), Black | |
| MJ2-M32CKA-1U-*** | 1 RU | MCVJKA | 32 ch (32 slots) | |
| MJ2-M32CKA-1.5U-*** | 1.5 RU | MCVJKA | 32 ch (32 slots) | |
| MJ2-M32CKA-2U-*** | 2 RU | MCVJKA | 32 ch (32 slots) |
Key Features and Benefits
- Color: Black and custom colors are available.
- Designation Strips.
- Easy Front Mount Assembly.
- Designation Strip Dimensions
- 1RU : 426 mm × 6.2 mm (*1)
- 1.5RU: 426.5 mm × 16.7 mm
- 2RU : 420 mm × 18.4 mm (*2)
- 4RU : 431.8 mm × 13.2 mm
Note
4RU type is available in black color only.
4RU type can not be recessed.
for 4RU, one model only : VJ2 -M32-4U
(*1) MJ2 -M32CKA-1U- * 426mm × 8.5mm
(*2) MJ2 -M32CKA-2U- * 426.5mm × 16.7mm
[ Obsolete products ]
| Type | Model | Panel Size | Jack Type | Description |
|---|---|---|---|---|
| NO IMAGE | MJ2-M32CK-1U-BLK (Obsolete products) | 1 RU | MCVJK (Old Model) | 32 ch (32 slots) |
